Home / HCG20012, 223 ton Capacity, 11.81 in Stroke, Single-Acting, High Tonnage Hydraulic Cylinder
HCG20012, 223 ton Capacity, 11.81 in Stroke, Single-Acting, High Tonnage Hydraulic Cylinder
HCG20012, 223 ton Capacity, 11.81 in Stroke, Single-Acting, High Tonnage Hydraulic Cylinder

HCG20012, 223 ton Capacity, 11.81 in Stroke, Single-Acting, High Tonnage Hydraulic Cylinder

  • Enerpac
  • Lifting and Hydraulics
  • Hydraulic Ram, Single Acting, High Cycle, Steel, Nominal Capacity 200 ton, Stroke Length 11 3/4 in, Nominal Stroke Length 12 in, Effective Push Area 43.95 sq in, Max. Pressure 10,150 psi, Oil Capacity Push 519.06 cu in, Retracted Height 20 in, Extended Height 31.8 in, Outside Dia. 9.84 in, Plunger Dia. 5.51 in, Base Mounting Thread Size M12, Weight 363 lb, Series HCG, Includes (2) Lifting Eyes, Interchangeable Saddle, Overpressurization Valve, Bore Dia. 7.48 in

    graingerSKU: , mscSKU: , zoro_no: G5526937, mongo_id: 65bbe6243aaddbd5a900e3a2

Web Price
$11,844.99 / each
Qty

Product Details

Lift, Push
M12
Steel
7.48 in
China
200 tons
High Cycle
43.95 sq in
808 mm
(2) Lifting Eyes, Interchangeable Saddle, Overpressurization Valve
Steel
10,150 psi
200 ton
12 in
519.06 cu in
519.06 cu in
9.84 in
1
5.51 in
Not eligible for promotion
508 mm
HCG
Single Acting
300 mm
363 lb
