Home / HCG5012, 62 ton Capacity, 11.81 in Stroke, Single-Acting, High Tonnage Hydraulic Cylinder
HCG5012, 62 ton Capacity, 11.81 in Stroke, Single-Acting, High Tonnage Hydraulic Cylinder
HCG5012, 62 ton Capacity, 11.81 in Stroke, Single-Acting, High Tonnage Hydraulic Cylinder

HCG5012, 62 ton Capacity, 11.81 in Stroke, Single-Acting, High Tonnage Hydraulic Cylinder

  • Enerpac
  • Lifting and Hydraulics
  • Hydraulic Ram, Single Acting, High Cycle, Steel, Nominal Capacity 50 ton, Stroke Length 11 3/4 in, Nominal Stroke Length 12 in, Effective Push Area 12.17 sq in, Max. Pressure 10,150 psi, Oil Capacity Push 143.78 cu in, Retracted Height 17.56 in, Extended Height 29.4 in, Outside Dia. 5.12 in, Plunger Dia. 2.76 in, Base Mounting Thread Size M12, Weight 80 lb, Series HCG, Includes (2) Lifting Eyes, Interchangeable Saddle, Overpressurization Valve, Bore Dia. 3.94 in

    graingerSKU: 55PP02, mscSKU: , zoro_no: G5526815, mongo_id: 65bbe6cf3aaddbd5a9055dc7

Web Price
$4,462.49 / each
Qty

Product Details

Lift, Push
M12
Steel
3.94 in
China
50 tons
High Cycle
12.17 sq in
746 mm
(2) Lifting Eyes, Interchangeable Saddle, Overpressurization Valve
Steel
10,150 psi
50 ton
12 in
143.78 cu in
143.78 cu in
5.12 in
1
2.76 in
Not eligible for promotion
446 mm
HCG
Single Acting
300 mm
80 lb
