HCL1006, 113 ton Capacity, 5.91 in Stroke, Single-Acting, High Tonnage, Lock Nut Hydraulic Cylinder
HCL1006, 113 ton Capacity, 5.91 in Stroke, Single-Acting, High Tonnage, Lock Nut Hydraulic Cylinder
HCL1006, 113 ton Capacity, 5.91 in Stroke, Single-Acting, High Tonnage, Lock Nut Hydraulic Cylinder

HCL1006, 113 ton Capacity, 5.91 in Stroke, Single-Acting, High Tonnage, Lock Nut Hydraulic Cylinder

  • Enerpac
  • Lifting and Hydraulics
  • Hydraulic Ram, Single Acting, High Cycle, Steel, Nominal Capacity 100 ton, Stroke Length 5 7/8 in, Nominal Stroke Length 7 in, Effective Push Area 22.19 sq in, Max. Pressure 10,000 psi, Oil Capacity Push 131.02 cu in, Retracted Height 11.3 in, Extended Height 17.2 in, Outside Dia. 6.89 in, Base Mounting Thread Size M12, Weight 118 lb, Series HCL, Includes (2) Lifting Eyes, Interchangeable Saddle, Overpressurization Valve, Bore Dia. 5.31 in

    graingerSKU: 55PP11, mscSKU: , zoro_no: G5520953, mongo_id: 65bbe9c522d7a989a9978ff6

Web Price
$4,634.99 / each
Qty

Product Details

Lift, Push, Hold
M12
Steel
5.31 in
China
100 tons
High Cycle
22.19 sq in
437 mm
(2) Lifting Eyes, Interchangeable Saddle, Overpressurization Valve
Steel
10,000 psi
100 ton
7 in
131.02 cu in
131.02 cu in
6.89 in
1
TR 135 x 6
Not eligible for promotion
287 mm
HCL
Single Acting
150 mm
118 lb
