Home / HCL15012, 168 ton Capacity, 11.81 in Stroke, Single-Acting, High Tonnage Lock Nut Hydraulic Cylinder
HCL15012, 168 ton Capacity, 11.81 in Stroke, Single-Acting, High Tonnage Lock Nut Hydraulic Cylinder
HCL15012, 168 ton Capacity, 11.81 in Stroke, Single-Acting, High Tonnage Lock Nut Hydraulic Cylinder
HCL15012, 168 ton Capacity, 11.81 in Stroke, Single-Acting, High Tonnage Lock Nut Hydraulic Cylinder

HCL15012, 168 ton Capacity, 11.81 in Stroke, Single-Acting, High Tonnage Lock Nut Hydraulic Cylinder

  • Enerpac
  • Lifting and Hydraulics
  • Hydraulic Ram, Single Acting, High Cycle, Steel, Nominal Capacity 150 ton, Stroke Length 11 3/4 in, Nominal Stroke Length 12 in, Effective Push Area 33.14 sq in, Max. Pressure 10,000 psi, Oil Capacity Push 391.45 cu in, Retracted Height 18.07 in, Extended Height 29.9 in, Outside Dia. 8.46 in, Base Mounting Thread Size M12, Weight 287 lb, Series HCL, Includes (2) Lifting Eyes, Interchangeable Saddle, Overpressurization Valve, Bore Dia. 6.5 in

    graingerSKU: 55PP14, mscSKU: , zoro_no: G5528136, mongo_id: 65bbe7363aaddbd5a9080d73

Web Price
$8,682.49 / each
Qty

Product Details

Lift, Push, Hold
M12
Steel
6.5 in
China
150 tons
High Cycle
33.14 sq in
759 mm
(2) Lifting Eyes, Interchangeable Saddle, Overpressurization Valve
Steel
10,000 psi
150 ton
12 in
391.45 cu in
391.45 cu in
8.46 in
1
TR 165 x 6
Not eligible for promotion
459 mm
HCL
Single Acting
300 mm
287 lb
