Home / HCL2004, 223 ton Capacity, 3.94 in Stroke, Single-Acting, High Tonnage, Lock Nut Hydraulic Cylinder
HCL2004, 223 ton Capacity, 3.94 in Stroke, Single-Acting, High Tonnage, Lock Nut Hydraulic Cylinder
HCL2004, 223 ton Capacity, 3.94 in Stroke, Single-Acting, High Tonnage, Lock Nut Hydraulic Cylinder
HCL2004, 223 ton Capacity, 3.94 in Stroke, Single-Acting, High Tonnage, Lock Nut Hydraulic Cylinder

HCL2004, 223 ton Capacity, 3.94 in Stroke, Single-Acting, High Tonnage, Lock Nut Hydraulic Cylinder

  • Enerpac
  • Lifting and Hydraulics
  • Hydraulic Ram, Single Acting, High Cycle, Steel, Nominal Capacity 200 ton, Stroke Length 3 7/8 in, Nominal Stroke Length 5 in, Effective Push Area 43.95 sq in, Max. Pressure 10,000 psi, Oil Capacity Push 173.02 cu in, Retracted Height 11.34 in, Extended Height 15.3 in, Outside Dia. 9.84 in, Base Mounting Thread Size M12, Weight 231 lb, Series HCL, Includes (2) Lifting Eyes, Interchangeable Saddle, Overpressurization Valve, Bore Dia. 7.48 in

    graingerSKU: 55PP22, mscSKU: , zoro_no: G5522956, mongo_id: 65bbe95a22d7a989a994dce3

Web Price
$7,708.74 / each
Qty

Product Details

Lift, Push, Hold
M12
Steel
7.48 in
China
200 tons
High Cycle
43.95 sq in
388 mm
(2) Lifting Eyes, Interchangeable Saddle, Overpressurization Valve
Steel
10,000 psi
200 ton
5 in
173.02 cu in
173.02 cu in
9.84 in
1
TR 190 x 6
Not eligible for promotion
288 mm
HCL
Single Acting
100 mm
231 lb
