Home / LPL2002, 223 ton Capacity, 1.77 in Stroke, Low Height, Lock Nut Hydraulic Cylinder
LPL2002, 223 ton Capacity, 1.77 in Stroke, Low Height, Lock Nut Hydraulic Cylinder
LPL2002, 223 ton Capacity, 1.77 in Stroke, Low Height, Lock Nut Hydraulic Cylinder

LPL2002, 223 ton Capacity, 1.77 in Stroke, Low Height, Lock Nut Hydraulic Cylinder

  • Enerpac
  • Lifting and Hydraulics
  • Hydraulic Ram, Single Acting, Low Profile, Steel, Nominal Capacity 200 ton, Stroke Length 1 3/4 in, Nominal Stroke Length 2 in, Effective Push Area 43.95 sq in, Max. Pressure 10,150 psi, Oil Capacity Push 77.9 cu in, Retracted Height 6.1 in, Extended Height 7.9 in, Outside Dia. 9.65 in, Weight 121 lb, Series LPL, Includes (2) Lifting Eyes, Interchangeable Saddle, Overpressurization Valve, Bore Dia. 7.48 in

    graingerSKU: null, mscSKU: null, zoro_no: G5529466, mongo_id: 65bbe5df3aaddbd5a9ff1742

Web Price
$8,034.99 / each
Qty

Product Details

Lift, Push, Hold
Steel
7.48 in
China
200 tons
Low Profile
43.95 sq in
200 mm
(2) Lifting Eyes, Interchangeable Saddle, Overpressurization Valve
Steel
10,150 psi
200 ton
2 in
77.9 cu in
77.9 cu in
9.65 in
1
TR 190 x 6
Not eligible for promotion
155 mm
LPL
Single Acting
45 mm
121 lb
