Air Compressor Pump, 20 hp, 25 hp, 30 hp, 2 Stage, 6.3333 qt Oil Capacity, 4 Cylinder
Air Compressor Pump, 20 hp, 25 hp, 30 hp, 2 Stage, 6.3333 qt Oil Capacity, 4 Cylinder

Air Compressor Pump, 20 hp, 25 hp, 30 hp, 2 Stage, 6.3333 qt Oil Capacity, 4 Cylinder

  • Speedaire
  • Pumps
  • Air Compressor Pump, Lubrication Type Splash Lubricated, Number of Stages 2, Maximum Output Power 30 hp, Free Air Flow Rate @ Maximum Pressure 76.7/90.1/101.0 cfm @ 175 psi, Number of Cylinders 4, Maximum Operating Pressure 175 psi, Flywheel Diameter 22 in, Flywheel Included Yes, Pump Speed 890 RPM, Construction Cast Iron, Groove Section B, Number of Grooves 3, Valve Type Disc, Valve Material Swedish Steel, Rotation CCW, Stroke Length 4 in

    graingerSKU: 3Z411, mscSKU: , zoro_no: G0346805, mongo_id: 65bbe64b3aaddbd5a901e632

Web Price
$11,348.74 / each
Qty

Product Details

3 1/4 in, 6 1/4 in
3.25 in, 6.25 in
Cast iron
United States
Green Metallic
22 in
22 in
Yes
76.7/90.1/101.0
76.7/90.1/101.0 cfm @ 175 psi
3
B
20 hp, 25 hp, 30 hp
Yes
Splash Lubricated
175 psi
175 psi
30 hp
11-3/8 in W x 11-1/4 in D
1 1/4
4
3
2
6.3333 qt
NPT
1.25 in
27 1/4 in
33 9/16 in
33 in
1
655, 770, 890
890 RPM
CCW
8 3/8 in, 9 7/8 in, 11 3/8 in
4 in
Swedish Steel
Disc
